MARIN SAN QUENTIN 29" 2 2024

Dirt jump DNA with all the speed and roll-over of 29" wheels. The Marin San Quentin 2 29 is our mid-pack model that blends bang-for-your-buck value with kick-ass components. We’ve packed in 29" wheels, a TranzX dropper post, X-Fusion suspension fork, Tektro brakes, Vee Tire rubber and plenty of awesome Marin kit to create a bike you’ll love to rip, but that won’t shred your budget. Dirt jump DNA with all the speed and roll-over of 29" wheels.

SPECIFICATIONS

FRAME
All New Series 3 6061 Aluminum, Double Butted, Internal Cable Routing, 12x148mm Thru-Axle, 73mm Threaded BB

FRONT SUSPENSION
X-Fusion Slide Boost RC, 29", 140mm Travel, Compression and Rebound Adjustment, 110x15mm Thru Axle, 44mm Offset

RIM
Marin Aluminum Double Wall, Disc Specific, 29mm Inner, Pinned Joint, 32H, Tubeless Compatible

HUB REAR
Shimano FH-TC500, 148x12, MicroSpline Freehub Body, Centerlock Disc, 32H

HUB FRONT
Shimano HB-TC500, 110x15mm

SPOKES NIPPLES
14g Black Stainless Steel

TIRES
Vee Tire Co, Flow Snap, 29x2.6", MPC Compound, Wire Bead

DERAILLEUR REAR
Shimano Deore, 11-Speed, SGS

SHIFT LEVER
Shimano Deore, 11-Speed, SL-5100R

CRANKSET
Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing

BOTTOM BRACKET
External Sealed Cartridge Bearing

CHAIN
Shimano CN-LG500

CASSETTE
Shimano CS-5100-11, 11-51T

BRAKES FRONT
Tektro M535 4-Piston Hydraulic, 180mm Rotor

BRAKES REAR
Tektro M535 4-Piston Hydraulic, 180mm Rotor

BRAKE LEVERS
Tektro M535

HANDLEBAR
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back

STEM
Marin 3D Forged Alloy, 35mm

GRIPS
Marin Grizzly Lock On

HEADSET
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”

SEATPOST
TranzX, YSP18, 1x Remote, All Sizes 170mm Travel, 30.9mm

SADDLE
Marin Speed Concept

PEDALS
Marin Oso OE Flat


Specifications, pricing, and availability are subject to change without notice.
