MARIN TEAM MARIN 1 2024

CROSS COUNTRY RACING

FUN TRAINING & TRAIL RIDING

XC LIGHT WITH TRAIL RIDING CAPABILITY

We made the Team Marin to be lightning-fast, super composed in the rough-and-tumble of spicy singletrack and perfectly in control up, along and down. It packs all the roll-up-your-sleeves tough of a trail bike and the zip you’d expect from an XC racer to perfectly blend speed with fun. Because who said XC had to be so serious?!

Champagne dreams on a cola budget. The Team Marin 1 brings XC-racer performance to a privateer price-point, all whilst staying super fun and super capable in the singletrack.

We started with a high-end Series 4 aluminum frame and fast-rolling 29” wheels and then added a capable RockShox Judy Silver fork, 12-speed Shimano drivetrain, Shimano hydraulic brakes and Vee Tire rubber to create a super fun, super affordable XC trail shredder.

SPECIFICATIONS

FRAME
Series 4 6061 Aluminum, 29" Wheels, Superlight Aluminum, Post-Mount Rear Brake, Internal Shifter and Dropper Post Routing, 148x12mm Boost Thru-Axle

FRONT SUSPENSION
RockShox Judy Silver TK, 120mm Travel, Alloy Tapered Steerer, Solo Air Spring, 110x15mm Boost Spacing, Maxle Stealth, 51mm Offset

RIM
Marin Aluminum Double Wall, 29mm Inner, Sleeve Joint, Disc Specific, Tubeless Compatible

HUB REAR
Forged Aluminum, 148x12mm, Disc Specific, 32H

HUB FRONT
Forged Aluminum, 110x15mm, Disc, 32H

SPOKES
14g Black Stainless Steel

TIRES
Vee Tire, Rail Rocco XC, 29x2.3", Dual Control Compound, Folding Bead, Tubeless Ready

DERAILLEUR REAR
Shimano Deore, RDM6100, 12-Speed

SHIFT LEVER
Shimano Deore, SLM6100, 12-Speed

CRANKSET
Forged Alloy 1x12, Hollow Spindle, Steel Narrow Wide 32T Chainring

BOTTOM BRACKET
External Sealed Cartridge Bearings

CHAIN
KMC X12

CASSETTE
SunRace, 12-Speed, 11-51T

BRAKES FRONT
Tektro HDT280, Hydraulic, 180mm Rotor

BRAKES REAR
Tektro HDR285 Flat-Mount Hydraulic, 180mm Rotor

BRAKE LEVERS
Tektro Hydraulic

HANDLEBAR
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 4º Up, 9º Back

STEM
Marin 3D Forged Alloy, 35mm

GRIPS
Marin Single Clamp Locking

HEADSET
FSA No 42ACB, 1 1/8" x 1 1/2”

SEATPOST
Marin Alloy, 30.9mm

SADDLE
Marin Speed Concept

PEDALS
Marin Oso OEM Nylon Platform

Specifications, pricing, and availability are subject to change without notice.
