MARIN ALPINE TRAIL E1

MARIN ALPINE TRAIL E1

£4,499.00
£0.00 £4,499.00
Sale Enquire to Order
Tax included.
Size

To pay by Klarna, add to cart.

Collect in Store

Ride away with our Bike Click & Collect service. All bikes are built by a Cytec trained Mechanic and personally set up for you in store.

The Alpine Trail E Bosch is our biggest, baddest beast of a bike family, with 170mm of suspension up front, 160mm of MultiTrac 2 travel at the rear and a Bosch CX drive unit at its core, the Alpine Trail E is constructed  for riders who challenge themselves with the steepest, most technical terrain, and maximum range for big days in the mountains.

Specifications
SPEC AND PRICE BEING SUBJECT TO CHANGE WITHOUT NOTIFICATION

App
Bosch eBike Flow App

Range
115-55 miles/25-90km

Display
Bosch Kiox 400 Top Tube Display

Switch
Bosch BRC3300 Bluetooth Remote 22.2mm Clamp

Battery
PT800 Horizontal

Frame
All New Series 4 Alloy for Gen 5 CX Drive Unit, 160mm MultiTrac LT Suspension, Adjustable Headset & CS Length/Height, Integrated Battery/Charging Port, 148mm Rear Thru-Axle

Front Suspension
X-Fusion Vengence, 170mm Travel, 44mm Offset, 110x15mm Bolt-on Axle

Rear Suspension
X-Fusion H3A Air, 205x65, 30xM8 Lower Hardware, Custom Tune

Rim
New Marin, Double Wall Alloy, 29mm Inner, Sleeved Joint, Disc Specific, 32H, Tubeless Compatible

Hub Rear
Shimano HB-MT501B, 148x12mm, Centerlock, Micro Spline Freehub Body

Hub Front
Shimano HF-MT500B, 110x15mm, Centerlock

Spokes
14g Black Stainless Steel

Tires
Front: Schwalbe Magic Mary, Gravity Pro, Ultra Soft, Radial, 29x2.5" Rear: Schwalbe Magic Mary, Gravity Pro, Soft, Radial, 27.5x2.5"

Chainguide
e*thirteen e*Spec Chainguide

Derailleur Rear
Shimano CUES RD-U6000 GS, 10-Speed

Shift Lever
Shimano CUES SL-U6000-10R, 10-Speed

Crankset
Marin Forged eMTB Cranks, 150mm

Chain
Shimano LG500

Cassette
Shimano CS-LG300-10, 11-48T

Brakes Front
TRP DHR EVO Comp, 200mm Rotors

Brakes Rear
TRP DHR EVO Comp, 200mm Rotors

Brake Levers
TRP DHR EVO Comp

Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back

Stem
Marin 3D Forged Alloy, 35mm

Grips
Marin Grizzly Lock-On

Headset
FSA Custom Headset, Adjustable HTA Design

Seatpost
TranzX YS160QL Adjustable Travel Dropper Post, Size S=150, M=170mm Travel, Size L-XL 200mm Travel, 34.9mm

Saddle
Marin Short Nose
