MARIN ALPINE TRAIL EXR

The Alpine Trail E Bosch is our biggest, baddest beast of a bike family, with 170mm of suspension up front, 160mm of MultiTrac 2 travel at the rear and a Bosch CX drive unit at its core, the Alpine Trail E is constructed  for riders who challenge themselves with the steepest, most technical terrain, and maximum range for big days in the mountains.

Specifications
SPEC AND PRICE BEING SUBJECT TO CHANGE WITHOUT NOTIFICATION

App
Bosch eBike Flow App

Range
115-55 miles/25-90km

Display
Bosch Kiox 400 Top Tube Display

Switch
Bosch BRC3300 Bluetooth Remote 22.2mm Clamp

Battery
PT800 Horizontal

Frame
All New Series 4 Alloy for Gen 5 CX Drive Unit, 160mm MultiTrac LT Suspension, Adjustable Headset & CS Length/Height, Integrated Battery/Charging Port, 148mm Rear Thru-Axle

Front Suspension
RockShox Zeb Ultimate, 170mm Travel, 29", 110x15mm Maxle Stealth, 44mm Offset

Rear Suspension
RockShox Vivid Air Ultimate, 205x65, 30xM8 Lower Hardware, Custom Tune

Rim
DT Swiss M552, 29mm Inner, 32H

Hub Rear
DT Swiss 370 Hybrid, 148x12mm, 6-Bolt Disc, Mircro Spline Driver, 32H

Hub Front
DT Swiss 370 Hybrid, 110x15mm, 6-Bolt Disc, 32H

Spokes
DT Swiss Champion Spokes, Pro Lock Nipples

Tires
Front: Schwalbe Magic Mary, Gravity Pro, Ultra Soft, Radial, 29x2.5" Rear: Schwalbe Magic Mary, Gravity Pro, Soft, Radial, 27.5x2.5"

Chainguide
e*thirteen e*Spec Chainguide

Derailleur Rear
SRAM GX AXS T-Type

Shift Lever
SRAM AXS Pod Infinity Mount

Crankset
Sram GX, 34T, 150mm

Chain
SRAM GX T-Type

Cassette
SRAM CS-XS-1275 T-Type, 10-52T

Brakes Front
SRAM Maven Silver, 4-Piston Hydraulic Disc, HSC 200mm Rotor

Brakes Rear
SRAM Maven Silver, 4-Piston Hydraulic Disc, HSC 200mm Rotor

Brake Levers
SRAM Maven Silver

Handlebar
PNW Range Handlebar, 38mm Rise, 35mm Clamp, 800mm Width

Stem
All New Marin CNC, 35mm Length, 35mm Bar Bore

Grips
Marin Grizzly Lock-On

Headset
FSA Custom Headset, Adjustable HTA Design

Seatpost
PNW Loam Post with Range Lever, Size S=150, M=170mm Travel, Size L-XL 200mm Travel, 34.9mm

Saddle
WTB Devo Pick-Up
