MARIN GESTALT XR 2025

ADVENTURE ON AND OFF-ROAD RIDING

LONG DISTANCE COMMUTING

GRAVEL RIDING

The Gestalt X is our hard-charging, rough-and-rowdy take on what gravel and adventure bikes can do. Break off the fire road, down the singletrack and charge further and faster than ever before. All while keeping the versatility, challenge and fun of a bike with drop handlebars.

The Gestalt X is built with a longer-than-the-usual wheelbase, slack-like-your-mountain-bike head angle, low-slung frame, wide bars, short stem, big and chunky tires with room for up to 50mm on 700c or 54mm with a 650b wheelset.

The Gestalt XR takes gravel to the next level. XR brings our MTB-inspired, Series 3 aluminum Gestalt X frame and adds a gravel-specific SRAM Apex 12-speed drivetrain, Apex hydraulic disc brakes, a TranzX dropper post, cushy and grippy 44mm wide Vee Tire Rubber and heaps of our own bespoke Marin components.

Specifications

• Frame

  Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle

• Fork

  Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets

• Rim

  Marin Aluminum Double Wall, 25mm Inner, 18mm Tall, Disc Specific, Tubeless Compatible

• Hub Rear

  Forged Aluminum Alloy, 142x12mm, Disc, 32H

• Hub Front

  Forged Aluminum Alloy, 100x12mm, Disc, 32H

• Spokes Nipples

  14g Black Stainless Steel

• Tires

  Vee Tire Co., Rocket Man, 700x44, Tubeless Compatible

• Derailleur Rear

  SRAM Apex 1 12-Speed

• Derailleur Front

  -

• Shift Lever

  SRAM Apex 1 1x12-Speed

• Crankset

  SRAM Apex 1, 40T

• Bottom Bracket

  SRAM DUB BSA

• Chain

  SRAM NX

• Cassette

  SRAM CS-XG-1275, 10-52T

• Brakes Front

  SRAM Apex 1 Flat-Mount Hydraulic Disc, 160mm Rotor

• Brakes Rear

  SRAM Apex 1 Flat-Mount Hydraulic Disc, 160mm Rotor

• Brake Levers

  SRAM Apex 1 Hydraulic Disc

• Handlebar

  Marin Butted Alloy, Compact 16º Flared Drop

• Stem

  Marin 3D Forged Alloy

• Grips

  Marin Shock Absorbing Perforated Tape

• Headset

  FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”

• Seatpost

  TranzX YSP38J, Size S-M 70mm, Size L-XL 110mm Travel, 27.2mm

• Saddle

  Marin Beyond Road Concept Elite

• Pedals

  -

• Extras

  Bolt-On Thru-Axles F and R

Specifications, pricing, and availability are subject to change without notice.
