MARIN RIFT ZONE EL XR 2025
MARIN RIFT ZONE EL XR 2025
To pay by Klarna, add to cart.
Collect in Store
Collect in Store
Ride away with our Bike Click & Collect service. All bikes are built by a Cytec trained Mechanic and personally set up for you in store.
The all-new Rift Zone EL ("Electric Light") trail eMTBs take everything you love about the Rift Zone and repurposes it into bikes that share the capability of the full-powered versions but in lighter packages.
Made possible in part by Bosch's new lightweight Performance Line SX drive unit and CompactTube internal battery, the Rift Zone EL models deliver a decidedly playful ride with a power delivery so natural you might forget its an ebike. With all the benefits without the bulk, the Rift Zone EL is the perfect platform for those who don't require the full range and power output of more traditional eMTBs.
The flagship Rift Zone EL XR is decked out with a gamut of high performance components, including the impressive Fox 36/Float X Performance Elite suspension combo, SRAM's GX AXS wireless T-type transmission drivetrain and Magura MT-7 4-piston brakes.
-
Frame
All New Series 4 Alloy Lightweight E, 140mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle
-
Front Suspension
Fox 36 Performance Elite, 150mm Travel, 29", 110x15 Kabolt, 44mm Offset
-
Rear Suspension
Fox Float X, Performance Elite, EVOL Air Spring, Climb Switch, Rebound Adjustment, Custom Tune, 210x55mm, 25xM8 Upper Mount, No Lower DU or Hardware
-
Rim
Marin Aluminum Double Wall, 29" Diameter, 32mm Inner Rim Width, Welded Joint, Disc Specific, Tubeless Compatible
-
Hub Rear
Formula DC-711, 110x15, 6-Bolt, 32H
-
Hub Front
Formula DCL-3482, 4 Sealed Bearings, 148x12, XD Driver, 6-Bolt, 32H
-
Spokes
14g Black Stainless Steel
-
Tires
Front: Maxxis Minion DHF, 29x2.4" MAXXGRIP, Tubeless ready, EXO+, Rear: Maxxis Forecaster 29x2.4", Tubeless Ready MAXX TERRA EXO+
-
Derailleur Rear
SRAM GX AXS T-Type
-
Derailleur Front
-
-
Shift Lever
SRAM AXS POD
-
Crankset
e*thirteen e*spec Plus, 160mm Length, 34T
-
Motor
Bosch Performance Line SX, 600W, 55Nm torque, 20MPH Top Assisted Speed
-
Chain
SRAM GX T-Type
-
Cassette
SRAM CS-XS-1275 T-Type, 10-52T
-
Brakes Front
Magura MT7, 4-Piston Hydraulic Disc, E-Specific Pads, 203mm MDR Rotor
-
Brakes Rear
Magura MT7, 4-Piston Hydraulic Disc, E-Specific Pads, 203mm MDR Rotor
-
Brake Levers
Magura HC3
-
Handlebar
Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back
-
Stem
Marin CNC, 35mm Length, 35mm Bar Bore
-
Grips
Marin Grizzly Lock On
-
Headset
FSA Custom, Adjustable HTA Design
-
Seatpost
PNW Loam Post with Range Lever, Size S 150mm Travel, Size M-L 170mm Travel, Size XL 200mm Travel, 34.9mm
-
Saddle
Marin Speed Concept
-
Pedals
Marin MTB Plastic
-
Battery
Bosch CompactTube 400Wh Internal
-
Display
Bosch BRC3100 Systems Controller
-
Switch
Bosch BRC3300 Bluetooth Remote 22.2mm Clamp
-
Extras
e*thirteen e*Spec Chainguide
-
Extras
Bolt-On 12mm Thru-Axle, 174mm Length, 1.0 Thread Pitch, 16.5mm, Tapered Head, Bosch EB12.110.016; 2A Charger
-
Range, Charging Time
15-55 miles (Based on Rider Weight, Terrain, Climate and Level of Assist Used), 6 Hours (estimated, under ideal conditions)
Specifications, pricing, and availability are subject to change without notice.
