ORBEA DENNA M10i 2025

Denna is all about removing limits. Gravel-tuned assistance offers power for the steepest climbs, and range for the longest rides. Wide tire clearance and a frame designed for a smooth ride make big days in the saddle a pleasure.

Specs

Frame
Orbea Denna, Thru Axle 12mm x 142mm rear, thread M12xP1, internal cable routing.

Fork
Orbea Denna OMR ICR, full carbon, 1-1/8" - 1,5" tapered head tube compatible, Thru axle 12x100mm, thread M12xP1

Steerer tube
FSA 1-1/2" Integrated Aluminium Cup

Battery
Orbea Internal 420Wh

RANGE EXTENDER
N/A

Motor
Shimano EP801

Display
N/A

CHARGER
Orbea 2.Generation eBike Smart charger 42V/2-4A

Remote
EN600-L

Chainring
Alloy EP8 42t

Crank
Shimano Steps EM600

Shifters
Shimano R9270

Cassette
Shimano CS-M8100 10-51t 12-Speed

Rear derailleur
Shimano XT Di2 M8150 12s SGS Shadow Plus

Chain
Shimano M6100

Chainguide
Orbea eBike chainguide

Handlebar
OC Road Performance RP11 Carbon, Reach 80, Drop 125, w/Di2 hole

Stem
OC Road Performance RP10, -8º

Brakes
Shimano R9270 Hydraulic Disc

Wheels
Oquo Road Performance RP45TEAM

Tyres
Pirelli P ZERO™ Race X SmartEVO TLR 700x30c

Front Wheel Axle
Orbea Thru Axle 12x100mm M12xP1 Hollow

Rear Wheel Axle
Orbea Thru Axle 12x142mm M12xP1 Solid inner threaded

Seatpost
OC Performance XP10 Carbon, 27.2mm, Setback 0

Saddle
Selle San Marco Shortfit 2.0 Start Up Off Road Xilite

Mudguard
N/A

Handlebar Tape
Lizard DSP 2.5mm
