ORBEA RISE LT M10 2025

The Trail Shredder's eMTB. Rise LT offers 160mm / 150mm of plush travel with a progressive trail geometry.

FRAME
Orbea Rise LT OMR 2025, 150mm travel, 29" wheels, Concentric Boost 12x148

SHOCK
Fox Float X Factory 2-Pos Adjust Evol LV Kashima custom tune 210x55mm

FORK
Fox 36 Float Factory 160 Grip X QR15x110 Kashima

HEADSET
Alloy 1-1/2", Black Oxidated Bearing

BATTERY
Orbea Internal 420Wh OR 630Wh

RANGE EXTENDER
N/A

MOTOR
Shimano EP801 RS Gen2 MC

DISPLAY
N/A

CHARGER
Orbea 2.Generation eBike Smart charger 42V/2-4A

REMOTE
EN600-L

CHAINRING
e*thirteen Helix Core e*spec Direct Mount 32T 55mm ChainLine

CRANK
Shimano Steps EM600

SHIFTERS
Shimano SLX M7100 I-Spec EV

CASSETTE
Shimano CS-M7100 10-51t 12-Speed

REAR DERAILLEUR
Shimano XT M8100 SGS Shadow Plus

CHAIN
Shimano M7100

CHAINGUIDE
Orbea Rise chainguide

HANDLEBAR
OC Mountain Control MC10 Carbon, Rise 20, Width 800

STEM
OC Mountain Control MC20, 0º

COMPUTER MOUNT
OC Computer Mount CM-05, Garmin/Sigma

BRAKES
Shimano XT M8120 Hydraulic Disc

ROTORS
203mm Front /180mm Rear

WHEELS
Oquo Mountain Control MC32TEAM

TYRES
Maxxis Assegai 2.50" 60TPI 3CG/EXO+/TR MaxxGrip

TYRES
Maxxis Minion DHR II 2.40" WT FB 120 TPI 3C MaxxTerra Exo+ TR

SEATPOST
OC Mountain Control MC22, 31.6mm, Dropper

SEATPOST LEVER
Shimano SL-MT500 I-Spec EV

SADDLE
Fizik Terra Ridon X5 145mm

GRIPS
Ergon GE10

TOOLS
OC FLP Multitool MT-20, Hex 2, 3, 4, 5 + OC Rear axle lever (Hex 6 & valve core removal)

We reserve the right to make changes to the product and component information appearing on this site at any time without notice, including with respect to equipment, specifications, models, colors, and materials.
